analog

digital

phase shifters are used to continuously transform the delay of signal and adjust phase of measure system in rf transmission system and mainly used in phase-controlled antenna array radar.

tke-360-2-x-x phase shifters' average power 100w, frequency range dc-2ghz, adjustable phase 360°per ghz and totally 720° phase adjustable.

mechanical specifications

connectors

female pin

housing

temp range

dimensions

weight

brass nickel

plated

beryllium copper

gold plated

aluminum, blue

spray painting

operating: -10°c~ 50°c

non-operating: -40°c~ 70°c

analog: 390×134×30.5mm

digital: 395×134×50.5mm

1800g

rohs complient: yes

electrical specifications

model number	frequency range(ghz)	max vswr	insertion loss(db)	phase adjustment
tke-360-1-x-x	dc-1	1.40	≤1.5	0~360°
tke-360-2-x-x	dc-2	1.50	≤2.0	0~720°

notes: the first x refer to connector type, the second x refer to display mode.

nominal impedance: 50?

average power: 100w

peak power: 5kw (5μs pulse width with 2% duty cycle)

connector type: n (f, f), sma (f, f)

notes:

1. dimensions tolerance ±2%

2. dimensions and specifications refer to connector type n unless otherwise specified.
