dc-凯时k66
dc-blocks prevent dc current flow while permitting rf power to flow, thus to isolate dc power from signal sources and measure instruments with broadband performance and low insertion loss.
| no. | model number | frequency range(ghz) | max vswr | ins. loss(db) | dc voltage(v) | connector type | picture |
| 1 | gzl-2.4 | 0.01-50 | ≤1.45 | ≤1.0 | 50 | 2.4(m,f) |   |
| 2 | gzl-2.92 | 0.1-40 | ≤1.55 | ≤1.20 | 100 | 2.92 |  |
| 3 | db-gzl-6 | 0.08-6 | ≤1.20 | ≤0.30 | 3000 | n |  |
| 4 | gzl-n | 0.1-18 | ≤1.40 | ≤0.8 | 100 | n |  |
| 5 | gzl-sma | 0.1-26.5 | ≤1.50 | ≤0.8 | 100-250 | sma |  |
| 6 | blk | 0.01-6 | ≤1.40 | ≤0.5 | 72 | n,sma |  |
| 7 | fgzl-4.3/10 | 0.1-6 | ≤1.25 | ≤0.3 | 3000 | 4.3/10 |  |
| 8 | lim-shx- db-gzl-n | 0.08-3 | ≤1.15 | <0.25 | 3000 | n |  |
| 9 | lim-fgzl - 7/16 | 0.1-6 | ≤1.25 | <0.30 | 3000 | 7/16 (m-f) |  |
