coaxial fixed terminations(>500w)-凯时k66
▼ dc-10ghz, up to 10kw ▼ 50 ohm and 75 ohm impedance ▼ high reliability, repeatable performance▼ bulkhead or panel-mount ▼ air&oil cooling choice ▼ low im3 versions available▼ rohs compliance ▼ custom designs available
| no. | model number | average power(w) | peak power(kw) | frequency range(ghz) | vswr | connector type | picture |
| 1 | tf800a(af) | 800 | 10 | dc-4 | 1.20-1.45 | n,7/16 |   |
| 2 | wtf1000 | 1000 | 10 | dc-8 | 1.10-1.55 | n |  |
| 3 | gtf1000 | 1000 | 10 | dc-4 | 1.40 | n,7/16,l27 |  |
| 4 | gtf1500 | 1500 | 10 | dc-4 | 1.40 | n,7/16,l27 |  |
| 5 | gtf2000 | 2000 | 10 | dc-4 | 1.40 | n,7/16,l27 |  |
| 6 | tf1000a(af) | 1000 | 50 | dc-2 | 1.30 | n,7/16,l27 |  |
| 7 | tf1000b(bf) | 1000 | 50 | dc-2 | 1.30 | n,7/16,l27 |  |
| 8 | tf2000a(af) | 2000 | 50 | dc-2 | 1.30 | n,7/16,l27 |  |
| 9 | tf2000b(bf) | 2000 | 50 | dc-2 | 1.30 | n,7/16,l27 |  |
| 10 | tf3000 | 3000 | 50 | dc-2 | 1.50 | n,7/16,l27 |  |
| 11 | tf5000 | 5000 | 100 | dc-1 | 1.40 | l27,7/16,l52 |  |
| 12 | tf10000 | 10000 | 100 | dc-1 | 1.40 | l27,7/16,l52 |  |
