inset terminations are used in quantitatively absorbing energy of rf and microwave system, they are commonly used as dummy loads of antenna and transmitter.wndtf serial wide-band inset termination's average power from 50w-300w, frequency range from dc-18ghz and the features include wide frequency band, low vswr,excellent capacity in anti-pulse and anti-burnout etc.

pdf download

no.	model number	average power(w)	peak power(kw)	frequency range(ghz)	vswr	connector type	picture
1	stf5	5		dc-26.5	1.30	3.5mm,sma
2	stf10	10		dc-26.5	1.30	3.5mm,sma
3	stf20	20		dc-26.5	1.25-1.30	3.5mm,sma,n,tnc
4	stf30-a(b)	30		dc-26.5	1.25-1.30	3.5mm,sma,n,tnc
5	stf50-a(b)	50		dc-26.5	1.30-1.35	3.5mm,sma,n,tnc
6	wntf50	50	10	dc-18	1.10-1.55	n,sma
7	wntf60	60	10	dc-18	1.10-1.55	n,sma
8	wntf75	75	10	dc-18	1.10-1.55	n,sma
9	wntf150	150	10	dc-10	1.10-1.35	n,sma
10	wndtf50	50	10	dc-18	1.20-1.55	n,sma
11	wndtf100	100	10	dc-18	1.20-1.55	n,sma
12	wndtf200	200	10	dc-10	1.25-1.40	n,sma
13	wndtf300	300	10	dc-10	1.25-1.40	n,sma
14	ndtf50	50	10	dc-4	1.15-1.30	n,sma
15	ndtf100	100	10	dc-4	1.15-1.30	n,sma
16	ndtf200	200	10	dc-4	1.15-1.40	n,sma
17	ndtf250	250	10	dc-4	1.15-1.40	n,sma
18	ndtf300	300	10	dc-4	1.15-1.40	n,sma
