low intermodulation attenuators-凯时k66
▼ dc-3ghz, 2w-100w ▼ flatness attenuation value and accuracy▼ high reliability, repeatable performance ▼ bulkhead or panel-mount ▼intermodulation attenuators won't over -50dbc ▼ rohs compliance ▼ custom designs available
| no. | model number | average power(w) | peak power(kw) | frequency range(ghz) | vswr | nominal attenuation value(db) | connector type | picture |
| 1 | lim-ts2 | 2 | 0.5 | dc-3 | 1.20 | 3,6,10,20,30 | n(m,f) |   |
| 2 | lim-ts5 | 5 | 0.5 | dc-3 | 1.20 | 3,6,10,20,30 | n(m,f) |  |
| 3 | lim-dts10 | 10 | 1 | dc-3 | 1.20 | 3,6,10,20,30 | n(m,f) |  |
| 4 | lim-dts25 | 25 | 1 | dc-3 | 1.20 | 3,6,10,20,30 | n(m,f) |  |
| 5 | lim-dts50-a | 50 | 10 | dc-3 | 1.30 | 10,20,30 | n(m,f) |  |
| 6 | lim-dts100 | 100 | 10 | dc-3 | 1.30 | 10,20,30 | n(m,f) |  |
| 7 | dts100-0830-n-lim | 100 | 0.8-3 | 1.30 | 10,20,30,40 | n(m,f) |  |
|
| 8 | dts200-0830-n-lim | 200 | 0.8-3 | 1.30 | 10,20,3040 | n(m,f) |  |
|
| 9 | dts200-40-0.8-lim-din | 200 | 0.8 | 1.25 | 40 | din7/16f-din7/16f，silver-gilt |  |
|
| 10 | dts300-0830-n-lim | 300 | 0.8-3 | 1.30 | 10,20,30,40 | n(m,f) |  |
