高功率电阻-凯时k66

▼ dc-4ghz, 10-250w ▼ 阻值0.5-20000欧姆,标准阻值50～100欧姆▼ 低vswr, 可靠性和稳定性高 ▼带法兰或不带法兰安装。高功率电阻可作为分配器上的平衡电阻或作为电桥、耦合器的吸收端。具有工作频带宽、驻波系数低、抗脉冲、抗烧毁能力强的特点。

pdf下载

no.	型号	平均功率(w)	频率范围	最大驻波比	图片
1	shx10-50b4sf101	10	dc-4	1.30
2	shx10-50b6sf102	10	dc-6	1.40
3	shx10-50b4sf111	10	dc-4	1.30
4	shx10-50b6sf112	10	dc-6	1.40
5	shx10-50b4sf121	10	dc-4	1.30
6	shx10-50b6sf122	10	dc-6	1.40
7	shx10-50b6sf131	10	dc-6	1.30
8	shx10-50b6sf141	10	dc-6	1.30
9	shx10-50b6sf151	10	dc-6	1.30
10	shx20-50b2sf201	20	dc-6	dc-2:1.25; dc-6:1.35
11	shx20-50b2sf211	20	dc-2;dc-6	dc-2:1.25;dc-6:1.35
12	shx20-50b2sf221	20	dc-2;dc-6	dc-2:1.25;dc-6:1.35
13	shx50-50b2sf501	50	dc-2	1.35
14	shx50-50b2sf511	50	dc-2	1.35
15	shx100-50b2sf301	100	dc-2	1.35
16	shx150-50b3sf405	150	dc-3	1.25
17	shx250-50b1sf701	250	dc-1	1.35
18	shx300-50b3sf801	300	dc-3	1.20
19	shx10-100bdf161	10
20	shx10-100bdf171	10
21	shx10-100bdf181	10
22	shx20-100bdf231	20
23	shx50-100bdf521	50
24	shx100-100bdf311	100
25	shx150-100bdf411	150
26	shx250-100bdf711	250
27	shx400-100bdf741	400
28	shx800-100bdf801	800
29	sht10-50-bdc	10	dc-3	1.2
30	sht10-150bdc-1	10	dc-3	1.15
31	sht10-150bdc-2	10	dc-3	1.15
32	sht20-50-bdc	20	dc-3	1.2
33	sht60-50-bdc	60	dc-3	1.2
34	sht100-50-bdc	100	dc-3	1.2
35	sht10-50-b-4-sc-1	10	dc-4	1.15
36	sht10-50-b-4-sc-2	10	dc-4	1.15
37	sht10-50bdf	10	dc-3	1.2
38	sht10-50bdf-j	10	dc-3	1.2
39	sht20-50bdf	20	dc-3	1.2
40	sht20-50bdf-j	20	dc-3	1.2
41	sht50-50bdf-j-1	50	dc-3	1.2
42	sht50-50bdf-j-2	50	dc-3	1.2
43	sht50-50bdf-j-ght-1	50	dc-3	1.2
44	sht50-50bdf-j-ght-2	50	dc-3	1.2
45	sht60-50bdf-1	60	dc-3	1.2
46	sht60-50bdf-2	60	dc-3	1.2
47	sht100-50bdf-1	100	dc-3	1.2
48	sht100-50bdf-2	100	dc-3	1.2
49	sht100-50bdf-j-1	100	dc-3	1.2
50	sht100-50bdf-j-2	100	dc-3	1.2
51	sht150-50bdf-1	150	dc-3	1.2
52	sht150-50bdf-2	150	dc-3	1.2
53	sht150-50bdf-j	150	dc-3	1.2
54	sht150-50bdf-j-ght	150	dc-3	1.2
55	sht150-50bdf-k	150	dc-3	1.2
56	sht200-50bdf	200	dc-3	1.2
57	sht200-50bdf-k	200	dc-3	1.2
58	sht250-50bdf-1	200	dc-3	1.2
59	sht250-50bdf-2	200	dc-3	1.2
60	sht250-50bdf-k	250	dc-3	1.2
61	sht10-50bdl-1	10	dc-3	1.2
62	sht10-50bdl-j	10	dc-3	1.2
63	sht20-50bdl-1	20	dc-3	1.2
64	sht20-50bdl-2	20	dc-3	1.2
65	sht20-50bdl-j	20	dc-3	1.2
66	sht50-50bdl	50	dc-3	1.2
67	sht50-50bdl-j	50	dc-3	1.2
68	sht60-50bdl	60	dc-3	1.2
69	sht100-50bdl	100	dc-3	1.2
70	sht100-50bdl-j	100	dc-3	1.2
71	sht150-50bdl	150	dc-3	1.2
72	sht150-50bdl-j	150	dc-3	1.2
73	sht200-50bdl	200	dc-3	1.2
74	sht200-50bdl-j	200	dc-3	1.2
75	sht250-50bdl	250	dc-3	1.2
76	sht250-50bdl-j	250	dc-3	1.2
77	sht5-50-b-6-sf-j-s	5	dc-6	1.2
78	sht5-50-b-6-sf-s	5	dc-6	1.2
79	sht10-50-b-3-sf-s-ght	10	dc-6	1.2
80	sht10-50-b-6-sf-j-s	10	dc-6	1.2
81	sht10-50-b-6-sf-s	10	dc-6	1.2
82	sht10-50-b-6-sf-tc	10	dc-6	1.2
83	sht10-50-b-6-sf-tc-1	10	dc-6	1.2
84	sht10-50-b-6-sf-tl	10	dc-6	1.2
85	sht10-50-b-6-sf-tl-1	10	dc-6	1.2
86	sht10-50-b-6-sf-tr	10	dc-6	1.2
87	sht10-50-b-6-sf-tr-1	10	dc-6	1.2
88	sht20-50-b-3-sf-s-ght	20	dc-6	1.2
89	sht20-50-b-6-sf-tc	20	dc-6	1.2
90	sht20-50-b-6-sf-tc-1	20	dc-6	1.2
91	sht20-50-b-6-sf-tl	20	dc-6	1.2
92	sht20-50-b-6-sf-tl-1	20	dc-6	1.2
93	sht20-50-b-6-sf-tr	20	dc-6	1.2
94	sht20-50-b-6-sf-tr-1	20	dc-6	1.2
95	sht50-50-b-3-sf-j-tc-ght-1	50	dc-3	1.2
96	sht50-50-b-3-sf-j-tc-ght-2	50	dc-3	1.2
97	sht50-50-b-3-sf-j-tl-ght	50	dc-3	1.2
98	sht50-50-b-6-sf-tc	50	dc-6	1.2
99	sht50-50-b-6-sf-tl	50	dc-6	1.2
100	sht50-50-b-6-sf-tr	50	dc-6	1.2
101	sht60-50-b-3-sf-s-ght-1	60	dc-3	1.2
102	sht60-50-b-3-sf-s-ght-2	60	dc-3	1.2
103	sht100-50-b-3-sf-s-ght-1	100	dc-3	1.2
104	sht100-50-b-3-sf-s-ght-2	100	dc-3	1.2
105	sht150-50-b-3-sf-s-ght	150	dc-3	1.2
106	sht200-50-b-3-sf-s-ght-1	200	dc-3	1.2
107	sht200-50-b-3-sf-s-ght-2	200	dc-3	1.2
108	sht250-50-b-3-sf-s-ght	250	dc-3	1.2
109	sht300-50-b-3-sf-s-ght	300	dc-3	1.2
110	sht10-50-b-3-sl-ght	10	dc-3	1.2
111	sht20-50-b-3-sl-ght-2	20	dc-3	1.2
112	sht20-50-b-3-sl-ght-1	20	dc-3	1.2
113	sht50-50-b-3-sl-ght	50	dc-3	1.2
114	sht60-50-b-3-sl-ght	60	dc-3	1.2
115	sht100-50-b-3-sl-ght-1	100	dc-3	1.2
116	sht100-50-b-3-sl-ght-2	100	dc-3	1.2
117	sht150-50-b-3-sl-ght-1	150	dc-3	1.2
118	sht150-50-b-3-sl-ght-2	150	dc-3	1.2
119	sht150-50-b-3-sl-ght-3	150	dc-3	1.2
120	sht150-50-b-3-sl-ght-4	150	dc-3	1.2
121	sht200-50-b-3-sl-ght	200	dc-3	1.2
122	sht250-50-b-3-sl-ght	250	dc-3	1.2
123	sht300-50-b-3-sl-ght	300	dc-3	1.2
124	lim-shx60-50b3sf261	60	dc-3	1.2
125	lim-shx60-50b3sf262	60	dc-3	1.2
126		100	dc-3	1.2
127	lim-shx100-50b3sf312	100	dc-3	1.2
128		150	dc-3	1.4
129		200	dc-3	1.2
130	lim-shx200-50b3sf602	200	dc-3	1.2
131	lim-shx250-50b3sf701	250	dc-3	1.35
132	lim-shx250-50b3sf721	250	dc-3	1.2
