| no. |
型号 |
阻带频率(ghz) |
通带频率(ghz) |
驻波比 |
通带插损(db) |
抑制度(db) |
图片 |
| 1 |
3.6g 带通 shx-bpf-3-3.6-r60-sf |
|
3-3.6 |
|
≤1.5 |
≥60@6-10.8g |
  |
| 2 |
数传电台带通 shx-bpf-220-240-r50-s |
|
220-240 |
|
≤2 |
≥50db @150mhz |
 |
| 3 |
5g 低频带通 shx-bpf-693-713-r55-nf-1 |
|
693-713 |
|
2.5 |
55@690.5-715.5mhz |
 |
| 4 |
5g 低频带通 shx-bpf-693-713-r55-nf-2 |
|
693-713 |
|
2.5 |
55@683-723mhz |
 |
| 5 |
5g 低频带通 shx-bpf-770-790-r55-nf-1 |
|
770-790 |
|
2.5 |
55@767.5-792.5mhz |
 |
| 6 |
5g 低频带通 shx-bpf-770-790-r55-nf-2 |
|
770-790 |
|
2.5 |
55@760-800mhz |
 |
| 7 |
5g 低频带通 shx-bpf-814-834-r55-nf-1 |
|
814-834 |
|
2.5 |
55@ 811.5-836.5mhz |
 |
| 8 |
5g 低频带通 shx-bpf-814-834-r55-nf-2 |
|
814-834 |
|
2.5 |
55@804-844mhz |
 |
| 9 |
5g 低频带通 shx-bpf-839-859-r55-nf-1 |
|
839-859 |
|
2.5 |
55@ 836.5-861.5mhz |
 |
| 10 |
5g 低频带通 shx-bpf-839-859-r55-nf-2 |
|
839-859 |
|
2.5 |
55@829-869mhz |
 |
| 11 |
5g 低频带通 shx-bpf-870-890-r55-nf-1 |
|
870-890 |
|
2.5 |
55@867.5-892.5mhz |
 |
| 12 |
5g 低频带通 shx-bpf-870-890-r55-nf-2 |
|
870-890 |
|
2.5 |
55@860-900mhz |
 |
| 13 |
5g 低频带通 shx-bpf-905-925-r55-nf-1 |
|
905-925 |
|
2.5 |
55@ 902.5-927.5mhz |
 |
| 14 |
5g 低频带通 shx-bpf-905-925-r55-nf-2 |
|
905-925 |
|
2.5 |
55@895-935mhz |
 |
| 15 |
5g 中频带通 shx-bpf-1700-1720-r55-nf-1 |
|
1700-1720 |
1.2 |
2.5 |
55@1697.5-1722.5mhz |
 |
| 16 |
5g 中频带通 shx-bpf-1700-1720-r55-nf-2 |
|
1700-1720 |
1.2 |
2.5 |
55@1690-1730mhz |
 |
| 17 |
5g 中频带通 shx-bpf-1775-1795-r55-nf-1 |
|
1775-1795 |
1.2 |
2.5 |
55@1765-1805mhz |
 |
| 18 |
5g 中频带通 shx-bpf-1775-1795-r55-nf-2 |
|
1775-1795 |
1.2 |
2.5 |
55@1772.5-1797.5mhz |
 |
| 19 |
5g 中频带通 shx-bpf-1840-1860-r55-nf-1 |
|
1840-1860 |
1.2 |
2.5 |
55@1830-1870mhz |
 |
| 20 |
5g 中频带通 shx-bpf-1840-1860-r55-nf-2 |
|
1840-1860 |
1.2 |
2.5 |
55@1837.5-1862.5mhz |
 |
| 21 |
5g 中频带通 shx-bpf-1900-1920-r55-nf-1 |
|
1900-1920 |
1.2 |
2.5 |
55@1897.5-1922.5mhz |
 |
| 22 |
5g 中频带通 shx-bpf-1900-1920-r55-nf-2 |
|
1900-1920 |
1.2 |
2.5 |
55@1890-1930mhz |
 |
| 23 |
5g 中频带通 shx-bpf-1970-1990-r55-nf-1 |
|
1970-1990 |
1.2 |
2.5 |
55@1960-2000mhz |
 |
| 24 |
5g 中频带通 shx-bpf-1970-1990-r55-nf-2 |
|
1970-1990 |
1.2 |
2.5 |
55@1967.5-1992.5mhz |
 |
| 25 |
5g 中频带通 shx-bpf-2010-2030-r55-nf-1 |
|
2010-2030 |
1.2 |
2.5 |
55@ 2007.5-2032.5mhz |
 |
| 26 |
5g 中频带通 shx-bpf-2010-2030-r55-nf-2 |
|
2010-2030 |
1.2 |
2.5 |
55@2000-2040mhz |
 |
| 27 |
5g 高频带通 shx-bpf-2290-2310-r55-nf-1 |
|
2290-2310 |
1.2 |
2.5 |
55@2287.5-2312.5mhz |
 |
| 28 |
5g 高频带通 shx-bpf-2290-2310-r55-nf-2 |
|
2290-2310 |
1.2 |
2.5 |
55@2280-2320mhz |
 |
| 29 |
5g 高频带通 shx-bpf-2390-2410-r55-nf-1 |
|
2390-2410 |
1.2 |
2.5 |
55@2380-2420mhz |
 |
| 30 |
5g 高频带通 shx-bpf-2390-2410-r55-nf-2 |
|
2390-2410 |
1.2 |
2.5 |
55@2387.5-2412.5mhz |
 |
| 31 |
wifi带通 shx-bpf-2402-2422-r55-nf-1 |
|
2432-2422 |
1.2 |
2.5 |
55@2480-2520mhz |
 |
| 32 |
wifi带通 shx-bpf-2402-2422-r55-nf-2 |
|
2432-2422 |
1.2 |
2.5 |
|
 |
| 33 |
wifi带通 shx-bpf-2432-2452-r55-nf-1 |
|
2432-2452 |
1.2 |
2.5 |
|
 |
| 34 |
wifi带通 shx-bpf-2432-2452-r55-nf-2 |
|
2432-2452 |
1.2 |
2.5 |
|
 |
| 35 |
wifi带通 shx-bpf-2462-2482-r55-nf-1 |
|
2462-2482 |
1.2 |
2.5 |
|
 |
| 36 |
wifi带通 shx-bpf-2462-2482-r55-nf-2 |
|
2462-2482 |
1.2 |
2.5 |
|
 |
| 37 |
5g 高频带通 shx-bpf-2490-2510-r55-nf-1 |
|
2490-2560 |
1.2 |
2.5 |
55@2480-2520mhz |
 |
| 38 |
5g 高频带通 shx-bpf-2490-2510-r55-nf-2 |
|
2490-2560 |
1.2 |
2.5 |
55@2487.5-2512.5mhz |
 |
| 39 |
5gnr系列带通 shx-bpf-2496-2596-r55-nf-1 |
|
2496-2596 |
1.2 |
2.5 |
55@2046-2601mh |
 |
| 40 |
5gnr系列带通 shx-bpf-2496-2596-r55-nf-2 |
|
2496-2596 |
1.2 |
2.5 |
55@2446-2646mhz |
 |
| 41 |
5g 高频带通 shx-bpf-2540-2560-r55-nf-1 |
|
2540-2560 |
1.2 |
2.5 |
55@2537.5-2562.5mhz |
|
| 42 |
5g 高频带通 shx-bpf-2540-2560-r55-nf-2 |
|
2540-2560 |
1.2 |
2.5 |
55@2530-2570mhz |
|
| 43 |
5g 高频带通 shx-bpf-2590-2610-r55-nf-1 |
|
2590-2610 |
1.2 |
2.5 |
55@2587.5-2612.5mhz |
|
| 44 |
5g 高频带通 shx-bpf-2590-2610-r55-nf-2 |
|
2590-2610 |
1.2 |
2.5 |
55@2580-2620mhz |
|
| 45 |
|
|
2590-2690 |
1.2 |
2.5 |
55@2585-2695mhz |
|
| 46 |
5g 高频带通 shx-bpf-2675-2695-r55-nf-1 |
|
2695-2695 |
1.2 |
2.5 |
55@2672.5-2697.5mhz |
|
| 47 |
5g 高频带通 shx-bpf-2675-2695-r55-nf-2 |
|
2695-2695 |
1.2 |
2.5 |
55@2665-2705mhz |
|
| 48 |
5gnr系列带通 shx-bpf-3300-3400-r55-nf-1 |
|
3300-3400 |
1.2 |
2.5 |
55@3250-3450mhz |
|
| 49 |
5gnr系列带通 shx-bpf-3300-3400-r55-nf-2 |
|
3300-3400 |
1.2 |
2.5 |
55@3295-3405mhz |
|
| 50 |
5gnr系列带通 shx-bpf-3700-3800-r55-nf-1 |
|
3700-3800 |
1.2 |
2.5 |
55@3650-3850mhz |
|
| 51 |
5gnr系列带通 shx-bpf-3700-3800-r55-nf-2 |
|
3700-3800 |
1.2 |
2.5 |
55@3695-3805mhz |
|
| 52 |
5gnr系列带通 shx-bpf-4100-4200-r55-nf-1 |
|
4100-4200 |
1.2 |
2.5 |
55@4350-4550mhz |
|
| 53 |
5gnr系列带通 shx-bpf-4100-4200-r55-nf-2 |
|
4100-4200 |
1.2 |
2.5 |
55@4095-4205mhz |
|
| 54 |
5gnr系列带通 shx-bpf-4400-4500-r55-nf-1 |
|
4400-4500 |
1.2 |
2.5 |
55@4395-4505mhz |
|
| 55 |
5gnr系列带通 shx-bpf-4400-4500-r55-nf-2 |
|
4400-4500 |
1.2 |
2.5 |
55@4395-4505mhz |
|
| 56 |
5gnr系列带通 shx-bpf-4650-4750-r55-nf-1 |
|
4650-4750 |
1.2 |
2.5 |
55@4600-4800mhz |
|
| 57 |
5gnr系列带通 shx-bpf-4650-4750-r55-nf-2 |
|
4650-4750 |
1.2 |
2.5 |
55@4650-4755mhz |
|
| 58 |
5gnr系列带通 shx-bpf-4900-5000-r55-nf-1 |
|
4900-5000 |
1.2 |
2.5 |
55@4895-5005mhz |
|
| 59 |
5gnr系列带通 shx-bpf-4900-5000-r55-nf-2 |
|
4900-5000 |
1.2 |
2.5 |
55@4850-5050mhz |
|
| 60 |
5g wifi带通 shx-bpf-5150-5310-r55-nf |
|
5150-5310 |
1.2 |
2.5 |
|
|
| 61 |
5g wifi带通 shx-bpf-5420-5580-r55-nf |
|
5420-5580 |
1.2 |
2.5 |
|
|
| 62 |
5g wifi带通 shx-bpf-5765-5925-r55-nf |
|
5765-5925 |
1.2 |
2.5 |
|
|
