50ω系列同轴固定负载(≤100w)-凯时k66

◇ dc-40ghz，1w-100w ◇ 工作频带宽，驻波系数低 ◇ 可靠性高，重复性好 ◇ 抗脉冲，抗烧毁能力强 ◇ 可按照客户要求设计和生产。同轴固定负载主要用于吸收射频或微波系统的功率，可作为天线的假负载和发射机终端。也可以作为多端口微波器件如环行器、方向耦合器的匹配端口，从而保证特性阻抗得到匹配，进行精确测量。

pdf下载

no.	型号	平均功率(w)	峰值功率(kw)	频率范围(ghz)	驻波比	连接器形式	图片
1	ssmpf&smpmf0.5-50	0.5	50	dc-50	1.80	smpm(f)/ssmp(f)
2	smpf1-20	1		dc-20	1.35	smp(m)
3	smpf2-50	2		dc-50	1.40	smp(m)
4	2.4tf2-50	2	0.2	dc-50	1.30-1.35	2.4mm
5	2.4tf5-50	5	0.2	dc-50	1.30-1.40	2.4mm
6	2.92tf2-40	2	0.2	dc-40	1.20-1.25	2.92
7	2.92tf5-40	5	0.2	dc-40	1.20-1.35	2.92
8	2.92tf10-40	10	0.2	dc-40	1.25-1.35	2.92
9	2.92tf20-40	20	0.2	dc-40	1.25-1.35	2.92
10	2.92tf50-40	50	0.2	dc-40	1.20-1.35	2.92mm
11	3.5tf2	2	0.5	dc-26.5	1.15-1.20	3.5mm
12	3.5tf5	5	0.5	dc-26.5	1.15-1.20	3.5mm
13	3.5tf10	10	0.5	dc-26.5	1.15-1.25	3.5mm
14	3.5tf25	25	0.5	dc-26.5	1.15-1.25	3.5mm
15	3.5tf50	50	0.5	dc-26.5	1.15-1.25	3.5mm
16	3.5tf100-26.5	100	0.5	dc-26.5	1.30-1.40	3.5mm,sma,smk
17	ssmaf	2	0.25	dc-18	1.15-1.30	sma
18	smafe	2	0.25	dc-18	1.10-1.35	sma(m)
19	smafg	2	0.25	dc-18	1.03-1.20	sma
20	sma-rpt	2	0.1	dc-12.4	1.15-1.25	sma(m) reverse polarity
21	smaf1-18	1	0.1	dc-18	1.05-1.30	sma(m)
22	smaf2	2	0.25	dc-26.5	1.20-1.25	sma
23	smaf5	5	0.5	dc-26.5	1.10-1.30	sma,3.5mm,2.92mm
24	qsmaf10	10	0.5	dc-6	1.20	qsma
25	smaf10	10	0.5	dc-26.5	1.10-1.30	sma,3.5mm,2.92mm
26	smaf25	25	1	dc-26.5	1.30	sma
27	smaf50	50	1	dc-26.5	1.30	sma
28	tf2-a(b)	2	0.5	dc-6	1.15-1.25	n,sma,bnc,tnc
29	tf2gh	2	0.5	dc-18	1.10-1.30	n
30	tf2-7/16-3g	2	1	dc-3	1.10	7/16(m)
31	tfe2	2	0.5	dc-8	1.10-1.25	n(m)
32	tfc5	5	0.5	dc-18	1.10-1.30	n
33	tf5	5	0.5	dc-6	1.15-1.25	n,bnc,sma,tnc,7/16
34	tfe5	5	1	dc-6	1.15-1.25	n(m)
35	tf5gh	5	0.5	dc-18	1.10-1.30	n
36	tf5-7/16-3	5	0.5	dc-3	1.10	7/16(m)
37	tf10	10	1	dc-6	1.15-1.20	n,bnc,sma,tnc
38	tf10gh	10	1	dc-18	1.30-1.40	n,sma
39	tfe10	10	1	dc-4	1.15-1.30	n
40	tf25	25	1	dc-6	1.15-1.25	sma,n,7/16,tnc,bnc
41	tf25gh	25	1	dc-18	1.20-1.40	n,sma
42	tfe25	25	1	dc-4	1.15-1.30	n
43	tf30	30	10	dc-6	1.10-1.30	n,sma,7/16,tnc,bnc
44	tfe30	30	1	dc-4	1.15-1.30	n
45	tf50-a	50	10	dc-4	1.05-1.20	n,sma,7/16,tnc
46	tfe50	50	1	dc-10	1.10-1.25	n
47	wtf50-a(b)(c)	50	5	dc-10	1.15-1.35	n,7/16
48	tf50gh-a(b)	50	1	dc-18	1.25-1.40	n,sma,tnc
49	tf50gh-c	50	5	dc-18	1.15-1.35	n,sma,tnc
50	tf60	60	1	dc-4	1.05-1.20	n,sma,7/16
51	tf60g	60	1	dc-10	1.15-1.40	n
52	tf80	80	10	dc-4	1.10-1.25	n,7/16,tnc
53	tf80gh	80	1	dc-18	1.20-1.40	n,sma,tnc
54	wtf80	80	5	dc-18	1.15-1.55	n,sma
55		100	5	dc-2	1.25	n(f)
56	tf100	100	10	dc-4	1.10-1.25	n,7/16
57	tf100g(f)	100	5	dc-18	1.25-1.40	n,sma,tnc
58	tf100g-c	100	5	dc-18	1.25-1.30	n,sma,tnc
59	wtf100	100	5	dc-18	1.15-1.55	n,sma
60	4.3/10tf10	10	1	dc-6	1.20-1.25	4.3/10
61	4.3/10tf25	25	1	dc-6	1.20-1.25	4.3/10
62	4.3/10tf50	50	5	dc-8	1.15-1.30	4.3/10
63	4.3/10tf100-d	100	5	dc-4	1.20-1.25	4.3/10
64	4.3/10wtf100	100	5	dc-6	1.20-1.30	4.3/10
65	4.3/10wtf150	150	5	dc-6	1.20-1.30	4.3/10
66	4.3/10wtf200	200	5	dc-6	1.20-1.30	4.3/10
67	qmaf-1	1	0.25	dc-6	1.15-1.20	qma
68	tf50-b(c)	50	1	dc-6	1.10-1.25	n,sma,tnc,bnc
